How to Set Up an eSIM on iPhone and Android (2026): Screen by Screen
The one setting almost everyone misses is Data Roaming on the travel line — off by default, and it decides whether you land connected or land stranded. Here is the whole setup drawn out screen by screen for both iPhone (Settings › Cellular) and Android (Settings › Network & internet › SIMs), including exactly where the roaming toggle hides on Pixel, Samsung, Xiaomi and OnePlus.
Published September 4, 2026·9 min read
30-day auto-refund on no usageSummary
A travel eSIM takes about five minutes to set up, and almost every first-time failure comes down to a single switch: Data Roaming on the travel line. It is off by default on both iPhone and Android, and while it is off the phone will show bars and load nothing. On iPhone it lives at Settings › Cellular › [travel line] › Data Roaming. On Android it is Settings › Network & internet › SIMs › [travel eSIM] › Roaming. Turning it on for the travel line cannot cost you anything on your home line — they are separate lines with separate roaming switches. Below is the whole flow drawn out, screen by screen, for both systems.
The one setting almost everyone misses
Here is the failure we see more than every other support ticket combined. Someone buys an eSIM, installs it perfectly at home, flies, lands, opens their phone — and gets a carrier name in the status bar with nothing behind it. Maps spins. WhatsApp will not send. It looks exactly like a broken eSIM.
It is not broken. Your travel eSIM is a foreign profile borrowing a local network, so your phone files it under roaming and, by default, refuses to pass data on it. The plan is fine, the coverage is fine, the phone is simply waiting for permission you have not given it yet.
That permission is one toggle, and it is in a different place on each system. Both are below, at the size you need when you are standing in an arrivals hall on 4% battery.
iPhone
Settings › Cellular › Travel eSIM
This is the one.
Off by default. Off means bars but no data — the phone will not attach to a network it considers foreign. On means the travel eSIM may use the local carrier it already paid for. Turn it on for this line only.
Android
Settings › Network & internet › SIMs › Travel eSIM
This is the one.
Android calls it Roaming, not Data Roaming, and it is per-SIM — switching it on here does nothing to your home line. Left off, it is the reason a brand-new eSIM shows a network and loads no pages.
Why this cannot give you a roaming bill
A roaming charge is your home carrier billing you for using a foreign network on your home line. The switch you just turned on is on a different line entirely — a prepaid local plan you already paid for, which cannot bill you again. Your home line keeps its own separate roaming switch, and that one stays off. Two lines, two toggles, and the expensive one never moves.
Before you fly: install on home Wi-Fi
Installing an eSIM downloads a profile from the internet. That is the one thing you will not have at an airport in a country where your phone has no service yet, so do this part while you still have Wi-Fi and time.
Installing early does not burn your plan. On travel plans the validity clock starts when the eSIM first connects to a network at your destination, not when you install it — so a week early is fine.
iPhone
Settings › Cellular
Step 1 — do this on Wi-Fi
Tap Add eSIM › Use QR Codeand point the camera at the QR in your order email. Installing pulls the profile down over the internet — which is exactly what you will not have standing in an arrivals hall.
Android
Settings › Network & internet › SIMs
Step 1 — do this on Wi-Fi
Tap Add eSIM › Scan QR code. On a Samsung Galaxy the same screen lives at Settings › Connections › SIM manager › Add eSIM. Either way, install it at home — the download needs a connection you will not have yet.
The full sequence, both systems
| Step | iPhone | Android (Pixel / stock) |
|---|---|---|
| 1. Install at home, on Wi-Fi | Settings › Cellular › Add eSIM › Use QR Code | Settings › Network & internet › SIMs › Add eSIM › Scan QR code |
| 2. Label it | Name the line “Travel” so you can tell the two apart at a glance | Same — rename the eSIM when prompted, or later from the SIMs list |
| 3. Protect the home line | Keep Home as Default Voice; open the Home line and leave its Data Roaming off | Keep Home for Calls and SMS; open the Home SIM and leave its Roaming off |
| 4. Point data at the travel line on landing | Settings › Cellular › Cellular Data › Travel eSIM | Settings › Network & internet › SIMs › Mobile data › Travel eSIM |
| 5. Turn on roaming the one that matters | Settings › Cellular › Travel eSIM › Data Roaming ON | Settings › Network & internet › SIMs › Travel eSIM › Roaming ON |
Steps 1–3 belong to the evening before your flight. Steps 4–5 take about twenty seconds at the gate or on landing. If you want to do 4 and 5 early too, that is fine — the travel line simply sits idle until it finds a network it is allowed to use.
Android: where each brand hid the roaming toggle
“Android” is not one menu. Every major manufacturer reorganised the network settings, and the roaming switch is the item they move most. If the Pixel path above does not match your phone, find your brand here:
| Phone | Add the eSIM | Roaming toggle |
|---|---|---|
| Google Pixel | Network & internet › SIMs › Add eSIM | Network & internet › SIMs › [eSIM] › Roaming |
| Samsung Galaxy (One UI) | Connections › SIM manager › Add eSIM | Connections › Mobile networks › Data roaming |
| Xiaomi / Redmi / POCO | SIM cards & mobile networks › Add eSIM | SIM cards & mobile networks › [SIM] › Data roaming |
| OnePlus / Oppo | Mobile network › Add eSIM (or SIM & network) | Mobile network › [SIM] › Data roaming |
Samsung is the one worth reading twice: it is the only major brand that puts roaming on a shared Mobile networks screen rather than inside the individual SIM, so check which SIM the screen is showing before you flip anything. If you are on a Galaxy, our Android dual SIM setup guidewalks through One UI's SIM manager in more detail.
When it still does not work
In rough order of how often each one turns out to be the answer:
| What you see | What it usually is | Fix |
|---|---|---|
| Bars, but nothing loads | Data Roaming off on the travel line | Turn it on, then toggle Airplane mode off and on to force a fresh attach |
| Everything works, home data allowance dropping | Mobile data still pointed at the home line | Switch the data line to the travel eSIM (step 4 above) |
| “No Service” / “Searching” | Phone latched onto a network the plan does not include | Network Selection › turn Automatic off, pick a listed carrier manually |
| QR code will not scan | Screen glare, or you are scanning from the same phone | Open the QR on a laptop or print it — or use Enter Details Manually |
| “This code is no longer valid” | The profile is already installed on this or another device | Check the SIMs list before re-scanning; an eSIM installs once |
| Data drains far faster than expected | Photo backup and app updates woke up on a real connection | Pause automatic updates and iCloud/Google Photos upload over cellular |
One thing that is not a fault: a fresh eSIM can take two or three minutes to register the first time it sees a foreign network. Turn roaming on, put the phone down, and let it finish before you start troubleshooting.
Does your phone support eSIM?
Two conditions: eSIM hardware, and not carrier-locked. A phone locked to your home carrier will refuse the profile no matter how correct your menus are, so if you are unsure, ask your carrier to unlock it before you buy anything.
- iPhone: every model from the iPhone XR and XS (2018)onward. US iPhone 14 models and later have no SIM tray at all — eSIM is the only option.
- Google Pixel: Pixel 3 and later.
- Samsung Galaxy: S20 and later, Note20, and the Z Fold and Z Flip line. Worth checking your exact model: Samsung ships eSIM-less variants of some phones in some regions.
- Others: recent OnePlus, Oppo, Motorola, Xiaomi and Huawei flagships, plus Rakuten Mini and most 2023-onward mid-range Motorola. Regional variation is the rule here, not the exception.
Keep your own number while you do this
Nothing above removes your home line. Both systems run two lines at once, which is the whole point: your home number stays reachable for calls, bank codes and two-factor texts, while the travel eSIM carries the data. You are not choosing between them.
The full version of that argument — what still works, what quietly stops, and what to set up before you go — is in our complete guide to keeping your number abroad.
FAQ
QDo I need to turn Data Roaming on for a travel eSIM?
AYes. A travel eSIM is a foreign profile visiting a local network, so the phone classes it as roaming and will not pass data until Data Roaming is on for that line. It is off by default, which is why the most common first-time failure is a phone that shows signal but loads nothing. Turn it on for the travel line only, and leave it off on your home line.
QWill turning on Data Roaming give me a huge bill?
ANot for the travel eSIM. Roaming charges come from your home carrier billing you for using a foreign network, and the toggle you switch on is on a completely separate line with its own prepaid allowance. Your home line has its own roaming toggle, which stays off. Turning roaming on for the travel line cannot trigger a charge on the home line.
QWhere is the Data Roaming toggle on Android?
AOn a Pixel it is Settings › Network & internet › SIMs › tap the travel eSIM › Roaming. On a Samsung Galaxy it is Settings › Connections › Mobile networks › Data roaming. On Xiaomi it is Settings › SIM cards & mobile networks › tap the SIM › Data roaming, and on OnePlus it is Settings › Mobile network › tap the SIM › Data roaming.
QShould I install the eSIM before I fly or after I land?
AInstall before you fly, on home Wi-Fi. Installing an eSIM downloads the profile over the internet, which is the one thing you do not have at an airport in a country where your phone has no service yet. Installing early does not start the plan — on most travel plans the clock starts when the eSIM first connects to a network at your destination.
QWhich phones can use a travel eSIM?
AOn Apple, every iPhone from the iPhone XR and XS (2018) onward, and US iPhone 14 models and later have no SIM tray at all. On Android, Pixel 3 and later, Galaxy S20 and later plus the Z Fold and Z Flip line, and recent OnePlus, Xiaomi, Motorola and Oppo flagships. The phone also has to be carrier-unlocked, and a few regional Android variants ship without eSIM hardware.
Related guides
- Keep your number abroad: the complete 2026 guide — the pillar this page sits under
- Data roaming ON or OFF?— the longer answer to why one line says yes and the other says no
- iPhone dual SIM setup for travel— running both lines properly on iOS
- Android dual SIM setup for travel— Pixel, Galaxy, OnePlus and Xiaomi
- Keep 2FA and bank codes working abroad — the reason you keep the home line alive
- eSIM vs SIM card— if you are still deciding
Bottom line
Install on Wi-Fi before you fly, keep your home line for calls and codes with its roaming off, point mobile data at the travel line, and turn Data Roaming on for that line only. That last toggle is the difference between landing connected and landing stranded, it is off by default on both iPhone and Android, and it cannot cost you anything on your home number.
